PCB spacer LPR872
Spacer to support the corners of the PCB. Corner seating on one side and snap on the other. For 4.8 to 22.2 mm spacing.
| 402344 LPR 8724 | 402393 LPR 8721 | 402394 LPR 8722 | 402395 LPR 8723 | 402396 LPR 8725 | 403590 LPR 8726 | 403591 LPR 8727 | |
|---|---|---|---|---|---|---|---|
| Distance height in mm | 12,7 | 4,8 | 6,4 | 9,5 | 15,9 | 19,1 | 22,2 |
| Mounting (A "top") | Supporting surface | Supporting surface | Supporting surface | Supporting surface | Supporting surface | Supporting surface | Supporting surface |
| Mounting (B "bottom") | Snap lock | Snap lock | Snap lock | Snap lock | Snap lock | Snap lock | Snap lock |
| Outer Diameter body in mm | 7,1 | 7,1 | 7,1 | 7,1 | 7,1 | 7,1 | 7,1 |
| Material | nylon 66 | nylon 66 | nylon 66 | nylon 66 | nylon 66 | nylon 66 | nylon 66 |
| Fire protection class | UL 94 V-2 | UL 94 V-2 | UL 94 V-2 | UL 94 V-2 | UL 94 V-2 | UL 94 V-2 | UL 94 V-2 |
| Colour | natural | natural | natural | natural | natural | natural | natural |
| Ø Mounting hole (B "bottom") in mm | 4,80 | 4,80 | 4,80 | 4,80 | 4,80 | 4,80 | 4,80 |
| Overlap (B "bottom") in mm | 5,6 | 5,6 | 5,6 | 5,6 | 5,6 | 5,6 | 5,6 |
| Panel thickness (A "top") in mm | 1,6 | 1,6 | 1,6 | 1,6 | 1,6 | 1,6 | 1,6 |
| Panel thickness (B "bottom") in mm | 1,6 | 1,6 | 1,6 | 1,6 | 1,6 | 1,6 | 1,6 |
