LED spacer ELBLI
LED spacer with fixing plates and a dividing wall, which will prevent a short circuit. Spacer enables overall length from 3.1 up to 10.9 mm.
| 403956 ELB LI-031 | 403957 ELB LI-041 | 403958 ELB LI-051 | 403959 ELB LI-061 | 403960 ELB LI-071 | 403961 ELB LI-081 | 403962 ELB LI-091 | 403963 ELB LI-099 | 409164 ELB LI-132 | |
|---|---|---|---|---|---|---|---|---|---|
| Material | crystalline polymer | crystalline polymer | crystalline polymer | crystalline polymer | crystalline polymer | crystalline polymer | crystalline polymer | crystalline polymer | crystalline polymer |
| Fire protection class | UL 94 V-0 | UL 94 V-0 | UL 94 V-0 | UL 94 V-0 | UL 94 V-0 | UL 94 V-0 | UL 94 V-0 | UL 94 V-0 | UL 94 V-0 |
| Colour | black | black | black | black | black | black | black | black | black |
| Ø Inner in mm | 3,4 | 3,4 | 3,4 | 3,4 | 3,4 | 3,4 | 3,4 | 3,4 | 3,4 |
| Ø Outer in mm | 5,1 | 5,1 | 5,1 | 5,1 | 5,1 | 5,1 | 5,1 | 5,1 | 5,1 |
| Height "H" in mm | 3,1 | 4,1 | 5,1 | 6,1 | 7,1 | 8,1 | 9,1 | 9,9 | 13,2 |
| Number of employed LEDs | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 |
| DH in mm | 1,5 | 1,5 | 1,5 | 1,5 | 7,7 | 4,7 | 4,7 | 7,9 | 11,1 |
| LED Size | 3 mm and 5 mm | 3 mm and 5 mm | 3 mm and 5 mm | 3 mm and 5 mm | 3 mm and 5 mm | 3 mm and 5 mm | 3 mm and 5 mm | 3 mm and 5 mm | 3 mm and 5 mm |
