Cable tie SST
Cable tie with bundle diameter from 1.5 to 203 mm and tensile strength up to 534 N
| 400009 SST 1M-N | 400015 SST 1.5M-N | 400019 SST 1.5I-N | 400022 SST 1.5S-N | 400025 SST 2I-N | 400029 SST 2S-N | 400032 SST 2H-N | 400037 SST 3I-N | 400040 SST 3S-N | 400046 SST 4S-N | |
|---|---|---|---|---|---|---|---|---|---|---|
| Material | polyamide 6.6 | polyamide 6.6 | polyamide 6.6 | polyamide 6.6 | polyamide 6.6 | polyamide 6.6 | polyamide 6.6 | polyamide 6.6 | polyamide 6.6 | polyamide 6.6 |
| Fire protection class | UL 94 V-2 | UL 94 V-2 | UL 94 V-2 | UL 94 V-2 | UL 94 V-2 | UL 94 V-2 | UL 94 V-2 | UL 94 V-2 | UL 94 V-2 | UL 94 V-2 |
| Temperature range | -60°C - +85°C | -60°C - +85°C | -60°C - +85°C | -60°C - +85°C | -60°C - +85°C | -60°C - +85°C | '-60°C - +85°C | -60°C - +85°C | -60°C - +85°C | -60°C - +85°C |
| Colour | natural | natural | natural | natural | natural | natural | natural | natural | natural | natural |
| Cable ties characteristics | Ends straight | Ends straight | Ends straight | Ends straight | Ends straight | Ends straight | Ends straight | Ends straight | Ends straight | Ends straight |
| Length in mm | 102 | 140 | 137 | 146 | 206 | 172 | 203 | 279 | 279 | 381 |
| Ø Bundle/ Cable in mm | 1,5 - 20 | 1,5 - 20 | 1,5 - 32 | 1,5 - 32 | 1,5 - 51 | 1,5 - 45 | 1,5 - 51 | 1,5 - 76 | 1,5 - 76 | 1,5 - 102 |
| Tensile strength in kg | 8,16 | 8,16 | 18,14 | 22,68 | 18,14 | 22,68 | 54,43 | 18,14 | 22,68 | 22,68 |
| Widths in mm | 2,4 | 2,4 | 3,4 | 4,6 | 3,4 | 4,6 | 7,6 | 3,4 | 4,6 | 4,6 |
| Lock type | locking | removable | locking | locking | locking | locking | removable | locking | locking | locking |
